by Gulfstream Model #HE110-RA
Free Shipping (Orders $500+)
No Sales Tax (Exceptions Apply)
Lowest Price Guarantee: Find a Lower Price? We'll Beat It!
Call Now, Talk with an Expert (864) 365-1762We're here to help!
Speak to a Gulfstream expert to see if the Gulfstream HE110RA Pool Heat Pump (Heat Only) is suitable for your needs. Reach out to us via phone or live chat. We're standing by to assist you.
Features:
Performance
| Phase | Single |
| kW Input | 5.0 |
| BTU Output | 115,000 BTU |
| COP Standard Rating Conditions 80/80/80 | 6.8 |
| BTU Output 80/80/63 | 100,000-109,000 BTU |
| COP 80/80/63 | 6.0 |
Model Specifications
| Pipe Size | 2" FIP |
| Mode | Heat Only |
| Fan Speed | 825 RPM |
| Fan Load Amperage | 1.8 |
| Fan Motor | 1/3 HP |
| Refrigerant Type | R-410A |
| Refrigerant/Factory Charge | 3.75 lbs |
| Display Controls | Digital |
| Thermostat | Digital |
| Compressor | Scroll |
| Compressor LRA | 145 |
| Compressor RLA | 26.9 |
| Heat Exchanger | 100% Titanium |
| Plumbing Size | 2" |
Electrical Specs
| Main Time Delay Breaker | 40 |
| Maximum Breaker Fuse Size | 50 |
| Hertz |
60 Hz |
| Phase Type | Single Phase |
| Voltage | 208/230 |
| Minimum Circuit Ampacity/Max Breaker | 37 |
| Average Running Amps | 19.7 |
Pool Water Flow
| Flow Rate: Min/Max | 30/70 GPM |
| Optimal Water Flow GPM | 45 GPM |
| Water Flow Min/Max GPM | 30/70 |
Physical Specifications
| Weight | 219 lbs |
| Dimension | 31" x 31" 38" |
| Shipping Weight | 255 lbs |
| Shipping Dimension | 33" x 31" 43" |
For more information regarding the warranty and returns for this product, please consult the manual below or contact customer service.
HE-Series Warranty
Manuals
HE-Series Manual
Gulfstream Installation Manual
Gulfstream Owners Manual
Gulfstream Brochure
Gulfstream Heat Pump Warranty Registration
Please call (864) 365-1762 or email: sales@gooutdoordirect.com for help with warranty, replacements, returns, or if you have any support-related questions.
